Remote operation Indication on the display Meaning
Setting
range:
Ohm OHM Ohm
kOhm KOHM kiloOhms
Calibrated RTD - Callendar-Van
Dusen
CVD Calibrated RTD - Callendar-Van Dusen coe󹪟‐
cients
Potentiometers POT Potentiometers
RTD Ptx - IEC 751, 10 ≤ x ≤ 10,000 PTX I RTD Ptx
1)
- IEC751, 10 ≤ x ≤ 10,000
1)
RTD Pt50 - IEC 751 P50 I RTD Pt50 - IEC 751
RTD Pt100 - IEC 751 P100I RTD Pt100 - IEC 751
RTD Pt200 - IEC 751 P200I RTD Pt200 - IEC751
RTD Pt500 - IEC 751 P500I RTD Pt500 - IEC 751
RTD Pt1000 - IEC 751 P1k I RTD Pt1000 - IEC 751
RTD Ptx - JIS C1604-81,
10 ≤ x ≤ 10,000
PTX J RTD Ptx
1)
- JIS C1604-81,
10 ≤ x ≤ 10,000
1)
RTD Pt50 – JIS C1604-81
(R100/R0 = 1.3916)
P50 J RTD Pt50 – JIS C1604-81
(R100/R0 = 1.3916)
RTD Pt100 - JIS C1604-81
(R100/R0 = 1.3916)
P100J RTD Pt100 - JIS C1604-81
(R100/R0 = 1.3916)
RTD Pt200 - JIS C1604-81
(R100/R0 = 1.3916)
P200J RTD Pt200 - JIS C1604-81
(R100/R0 = 1.3916)
RTD Nix - DIN 43760,
10 ≤ x ≤ 10,000
NIX D RTD Nix
1)
- DIN 43760,
10 ≤ x ≤ 10,000
1)
RTD Ni50 - DIN 43760 N50 D RTD Ni50 - DIN 43760
RTD Ni100 - DIN 43760 N100D RTD Ni100 - DIN 43760
RTD Ni120 - DIN 43760 N120D RTD Ni120 - DIN 43760
RTD Ni1000 - DIN 43760 N1k D RTD Ni1000 - DIN 43760
RTD Cux - ECW
No. 15, 5 ≤ x ≤ 1,000
CUX E RTD Cux
1)
- ECW No. 15, 5 ≤ x ≤ 1,000
RTD Cu10 - ECW No. 15
(α = 0.00427)
C10 E RTD Cu10 - ECW No. 15 (α = 0.00427)
RTD Cu100 - ECW No. 15
(α = 0.00427)
C100E RTD Cu100 - ECW No. 15 (α = 0.00427)
RTD Cu50 - GOST 6651-1994
(α = 0.00426)
C50G1 RTD Cu50 - GOST 6651-1994 (α = 0.00426)
RTD Cu50 - GOST 6651-2009
(α = 0.00428)
C50G2 RTD Cu50 - GOST 6651-2009 (α = 0.00428)
RTD Cu100 - GOST 6651-2009 (α
= 0.00428)
C1hG2 RTD Cu100 - GOST 6651-2009 (α = 0.00428)
RTD Pt50 – GOST 6651-2009
(α = 0.00391)
P50 G RTD Pt50 – GOST 6651-2009 (α = 0.00391)
RTD Pt100 – GOST 6651-2009
(α = 0.00391)
P100G RTD Pt100 – GOST 6651-2009 (α = 0.00391)
RTD Cu100 – GOST 6651-1994
(α = 0.00426)
C1hG1 RTD Cu100 – GOST 6651-1994 (α = 0.00426)
RTD Cux – GOST 6651-1994
(α = 0.00426)
CUX G RTD Cux
1)
– GOST 6651-1994 (α = 0.00426)
Parameter assignment
8.3 Parameter assignment over device with display
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
76 Operating Instructions, 08/2020, A5E47810090-AA
