Table 11-4 Gas Ex i/nA/ec
Header type BT0, AH0 BMO BP0
T
max
Header 80 °C 80 °C 100 °C
Temperature class T6 T6 T4 T6
Temperature
of medium (°C)
Tempera‐
ture rise
caused by
medi‐
um ΔT2G
(K)
Extension
length "X"
(mm)
T
2
in °C T
2
in °C T
2
in °C T
2
in °C
440 °C 23 43* 40 57 37 57 37
12 23* 80 68 57 77 57
6 11* 150 74 69 89 69
3 300 77 77 97 77
290 °C 22 40 58 58 78 58
11 80 69 69 89 69
5 150 75 75 95 75
2 300 78 78 98 78
200 °C 16 40 64 64 84 64
8 80 72 72 92 72
4 150 76 76 96 76
2 300 78 78 98 78
130 °C 9 40 71 71 91 71
5 80 75 75 95 75
3 150 77 77 97 77
1 300 79 79 99 79
80 °C 5 40 80 80 100 80
3 80 80 80 100 80
1 150 80 80 100 80
0 300 80 80 100 80
* Value for header type BP0 and BMO
Table 11-5 Type 2N
Header type AU0 AV0, SITRANS TF
T
max
Header 120 °C 85 °C
Temperature class T4 T6 T4 T6
Temperature of
medium (°C)
Temperature rise
caused by medi‐
um ΔT2G (K)
T
2
in °C T
2
in °C T
2
in °C T
2
in °C
100 °C 7 120 73 78 73
80 °C 5 120 80 85 80
