Table 12-4 Overview of SITRANS TS500 dimensional drawings
Versions Description
Type 2, pipe version without process
connection
• Temperature sensors for containers and pipelines, pipe version for low to medi‐
um stress, without process connection, without extension, for plugging-in or
use with sliding compression joints
• SITRANS TS500, types 2 and 2N (Page 159)
Type 2N, pipe version with screw-in nip‐
ple
• Temperature sensors for containers and pipelines, pipe version for low to medi‐
um stress, protective tube type 2N similar to DIN 43772, for screwing-in, without
extension, for process temperatures up to 100 °C (212°F)
• SITRANS TS500, types 2 and 2N (Page 159)
Type 2G, pipe version with screw-in nip‐
ple and extension
• Temperature sensors for containers and pipelines, pipe version for low to medi‐
um stress, protective tube in accordance with DIN 43772, type 2G, for screwing-
in, with extension
• SITRANS TS500, types 2G and 2F (Page 160)
Type 2F, pipe version with 󹪞ange and ex‐
tension
• Temperature sensors for containers and pipelines, pipe version for low to medi‐
um stress, protective tube in accordance with DIN 43772, type 2F, with 󹪞ange,
with extension
• SITRANS TS500, types 2G and 2F (Page 160)
Type 3, fast pipe version without process
connection
• Temperature sensors for containers and pipelines, pipe version for low to medi‐
um stress, without process connection, without extension, for plugging-in or
use with sliding compression joints
• SITRANS TS500, type 3 (Page 161)
Type 3G, fast pipe version with screw-in
nipple and extension
• Temperature sensors for containers and pipelines, pipe version for low to medi‐
um stress, protective tube in accordance with DIN 43772,
type 3G, for screwing-in, without process connection, with extension
• SITRANS TS500, types 3G and 3F (Page 162)
Type 3F, fast pipe version with 󹪞ange
and extension
• Temperature sensors for containers and pipelines, pipe version for low to medi‐
um stress, protective tube in accordance with DIN 43772, type 3F, with 󹪞ange,
with extension
• SITRANS TS500, types 3G and 3F (Page 162)
Types 4 and 4F, full material version,
with extension
• Temperature sensors for containers and pipelines, full material version for me‐
dium to very high stress, protective tube in accordance with DIN 43772, type 4,
for welding-in, with extension
• Protective tube type 4F, with 󹪞ange, with extension
• SITRANS TS500, types 4 and 4F (Page 163)
Type ST, threaded tapered well
(7MC65..)
• Temperature sensors for vessels and pipelines, threaded process connection,
tapered thermowell
• SITRANS TS500, type ST, threaded tapered well (7MC65..) (Page 164)
Type SST, threaded tapered well
(7MC55..)
• Temperature sensors for vessels and pipelines, threaded process connection,
tapered thermowell
• SITRANS TS500, type SST, threaded tapered well (7MC55..) (Page 166)
Type SS, threaded straight well
(7MC65..)
• Temperature sensors for vessels and pipelines, threaded process connection,
straight thermowell
• SITRANS TS500, type SS, threaded straight well (7MC65..) (Page 167)
