Versions Description
Type SWR, socket reduced well
(7MC55..)
• Temperature sensors for vessels and pipelines, socket well process connection,
tapered thermowell
• SITRANS TS500, type SWR, socket reduced well (7MC55..) (Page 184)
SITRANS TS500 for installation in exist‐
ing protective tubes
• Temperature sensors for containers and pipelines, temperature sensors for in‐
stallation in existing protective sleeves, suitable for sleeves in accordance with
DIN 43772 and ASME B40.9-2001, with extension of European or American
design
• SITRANS TS500 for installation in existing protective tubes (Page 185)
Type GP, general purpose, no well
• Temperature sensors for vessels and pipelines, threaded process connection, no
thermowell
• SITRANS TS500, type GP, general purpose, no well (Page 187)
Table 12-5 Overview of SITRANS TSinsert dimensional drawings: measuring inserts for retro󹪝tting and upgrading
Versions Description
European design
• Measuring inserts for temperature sensors, replaceable, mineral-insulated ver‐
sion, European design (DIN ceramic base),
spring approx. 8 mm (0.31 inch)
• SITRANS TSinsert - measuring inserts for SITRANS TS500 (Page 188)
American design
• Measuring inserts for temperature sensors, replaceable, mineral-insulated ver‐
sion, American design, spring approx. 25 mm (0.98 inch)
• SITRANS TSinsert - measuring inserts for SITRANS TS500 (Page 188)
Dimension drawings
12.1 Overview
SITRANS TS100/TS200/TS300/TS500/TSinsert/TSthermowell
152 Operating Instructions, 08/2020, A5E47810090-AA
