Field Name Description
IPv6 settings section
The following fields appear when either IPv6 Only or IPv4&IPv6 (Dual Stack) is selected in the Network Protocol
Selection field on the WAN Service Configuration page.
Obtain an IPv6 address auto-
matically
This option is set to enabled by default and allows the ISP to automatically assign
the WAN IP address to the gateway. To disable the DHCPv6 Client on this WAN
interface, click the radio button.
Dhcpv6 Address Assignment
(IANA)
Select this option for the CPE to receive the WAN IP from the ISP.
Dhcpv6 Prefix Delegation (IAPD) This option is selected by default. The CPE generates the WAN IP's prefix from the
server's REST by MAC address. To disable this option, clear the checkbox.
Use the following Static IPv6
address
Select this option to enter the v6 Static IP information provided by your ISP.
WAN IPv6 Address/Prefix
Length
(Available only when Static IPv6 address is selected) If entering a static IP
address, enter the IP address / prefix length. If you do not specify a prefix length,
the default of /64 is used.
Prefix Delegation/Prefix Length (Available only when Static IPv6 address is selected) (Optional) Enter the prefix
delegation ID and prefix length for WAN.
WAN Next-Hop IPv6 address (Available only when Static IPv6 address is selected) Enter the IP address of the
next WAN in the group. This address can be either a local link or a global unicast
IPv6 address.
Enable MAC Clone (Available for IPv4-only or IPv4-IPv6 Dual Stack environments) Select to enable
MAC cloning; then enter the MAC address that you want to clone.
To use the MAC address of the connected PC, click Clone the PC MAC Address.
To use a dynamic MAC address, leave this field as-is.
