24 EEI
24.1 EEI
Termination Addressing Interface
No Yes LAN
Overview
•
Integrated interface.
•
The inverter‘s IP address has to be assigned.
•
Connected using network cable (patch cable) and Ethernet router or switch.
•
Installation steps:
• The inverter‘s has to be assigned a static IP address.
• Switch off the inverters and Solar-Log™.
• Connect inverters to the Solar-Log™ (RJ45).
• Connect the inverters to each other (RJ45).
Connect inverters to the Solar-Log™
The wiring is done using a
•
network cable (patch cable/crossover cable) and the
•
Ethernet router or switch.
Connect the inverters to each other
The inverters are connected together using
the RJ45 interface and, if needed, a router or switch.
Connection setup according to the inverter‘s instructions.
Assigning IP addresses
•
A static IP address has to be assigned to the inverter via the display.
•
Please select an IP address with the same class C subnet as the Solar-Log™.
For example: The Solar-Log™ has the IP address 192.168.178.49.
The inverter in this case has to have a free IP address in the same range (from 192.168.178.1 to
192.168.178.254).
•
Procedure: Start according to the inverter‘s instructions.
Detection via the Solar-Log™ WEB Interface
•
For detection on the Solar-Log™ , select the device class under the menu Configuration | Device | Definition |
Interface with the plus symbol and then select EEI as the manufacturer. Confirm your selection with OK.
•
Save your selections and then start the Device Detection under Configuration | Device | Detection.
Detection from the Solar-Log 1200
•
When using the Solar-Log 1200, the detection can also be started from the display. Select the settings ►Start
► Initial Configuration ► Page 2 „Device“ ► Add and select the manufacturer EEI from there. Save and start
the Device Detection.
