Kipp & Zonen - Pyranometer
1 Kipp&Zonen-Pyranometer
1.1 Kipp&Zonen-Pyranometer
Termination Addressing Interface
Yes No RS485
Selections available under Kipp & Zonen
supported models:
•
SMP3
•
SMP11
Overview
•
Integrated interface.
•
Where to connect: Round socket on the bottom.
•
Communication address must be allocated.
•
4-pin wiring.
•
Installation steps:
• Switch off the pyranometer and the Solar-Log™.
• Connect the pyranometer to the Solar-Log™.
Connect the pyranometer to the Solar-Log 1000, 1200, 1900 or 2000.
The wiring is done using a
•
ready-made data cable (supplied with the pyranometer).
Pin assignment:
Solar-Log™ terminal strip connector X4 socket RS485-1 pyranometer
Terminal PIN
► 1 A / Data+ ► 4 - B / + (yellow)
► 212V ► 7 - 12 V (white)
► 3 GND ► 8 - Ground / GND (black)
► 4 B / Data- ► 5 - A / - (gray)
Termination:
Please contact Kipp & Zonen for information on termination.
Note
Only one pyranometer can be connected and visualized per Solar-Log™ device.
