Solare Datensysteme Solar-Log - 84.9 SMA - Sunny Tripower CORE1

307
SMA
84.9 SMA-SunnyTripowerCORE1
Termination Addressing Interface
No Yes LAN
Select “SMA: Sunspec CORE1“ for the device detection.
Supported models (as of firmware 4.1.0):
•
STP 50-40
Overview
•
Integrated interface
•
Connect using network cable (patch cable) and Ethernet router or switch.
•
The communication address has to be assigned.
•
Installation steps
• Assign the communication address.
• Connect the inverters to the Solar-Log™.
• Connect the inverters to each other.
Assign the communication address.
•
Assign the IP addresses according to the inverter‘s instructions.
Connect inverters and the Solar-Log™.
The wiring is done using a
•
network cable (patch cable) and the
•
Ethernet router or switch.
Procedure
1. Connect the Solar-Log™ and the inverter to the router or switch.
2. Assign an IP address to every inverter. Assign the IP addresses according to the inverter‘s instructions.
The first three number blocks like the Solar-Log™, e.g.
192.168.178.49.
The fourth number block: an address that is available, e.g. 192.168.178.
50.
Note
Each inverter has to be individually reachable via the network.
To do this, activate the network interface at each inverter via the SMA SUNNY EXPLORER and connect
the inverters into the network with a network switch.
Procedure:
► Set the „TCP Server“ to „On“ in the SMA SUNNY EXPLORER; Port=502.
New supported models (as of firmware 4.2.3):
•
STP33-US-41, STP50-US-41, STP62-US-41
