Riello
71Riello
71.1 Riello
Termination Addressing Interface
Yes No RS422
Overview
•
Interface not integrated; Retrofit RS485 interface card.
•
4-pin cable – only on RS485/422 B or C connection of the Solar-Log™
•
Communication address does not have to be assigned.
•
Multi-string technology
Riello inverters are fitted with 1 or 3 MPP trackers depending on the model. Each string input is monitored separa-
tely and ideally adjusted to the connected modules.
The Solar-Log™ automatically detects how many inverters and strings are active during inverter detection.
Note
The order in which the inverters are displayed in the Solar-Log™ after detection is random. We strongly
recommend that you change the order of the inverters immediately after detection at startup, in the
Configuration | Devices | Configuration | Order dialog box.
► The inverters can be identified using the displayed serial number.
•
Installation steps
• Switch off the inverters and Solar-Log™
• Install the RS485 interface in the inverter
• Connect inverters to the Solar-Log™
• Connect the inverters to each other
Installing the RS485 interface
Procedure
► Insert the RS485 interface in the bottom of the inverter in accordance with the interface card installation inst-
ructions and screw in.
Connect inverters to the Solar-Log™
The wiring is done using a
•
ready-made data cable (optional extra; not supplied)
or
•
self-made, shielded 4 wire data cable and terminal block connector.
