Solare Datensysteme Solar-Log - 89.2 SolaX Power X3

330
SolaX Power
89.2 SolaXPowerX3
Termination Addressing Interface
Yes Yes RS485
The following types are to be connected according to this diagram:
•
ZDNY-TL10000, ZDNY-TL12000, ZDNY-TL15000, ZDNY-TL17000
Select SolaXPower X3 during the inverter detection.
Overview
•
Integrated interface.
•
2 RJ45 sockets on the outside of the inverter.
•
2-pin wiring.
•
Communication address must be allocated.
•
Installation steps
• Switch off the inverters and Solar-Log™.
• Connect inverters to the Solar-Log™.
• Connect the inverters to each other
• Allocate communication address.
Address range 1 to 247
Settings on the inverter's display according to the manufacturer's manual.
Connect inverters to the Solar-Log™.
The wiring is done using a
•
self-made, shielded 8 wire data cable and terminal block connector.
•
Where to connect: RJ45 socket on the inverter
Procedure
1. If you make the cable yourself, connect the wires as shown in the following diagram.
Solar-Log™ terminal strip connector RS485 inverter socket
Terminal PIN
► 1 ► Pin 4 - Data+
► 4 ► Pin 5 - Data-
2. Insert the RJ45 plug into any RJ45 socket on inverter 1.
3. If no further inverter is connected, terminate the inverter according to the instructions for the inverter.
4. Insert the terminal block connector into the Solar-Log™ RS485 socket.
