Keba - Power Charging Station
1 Keba-PowerChargingStation
1.1 Keba-PowerChargingStation(KeContactP20/P30)
Termination Addressing Interface
No Yes LAN
Supported models:
•
KeContact P20
• c series
• x series
•
KeContact P30
• c series
• x series
Overview
•
Connected using network cable (patch cable) and Ethernet router or switch.
•
Installation steps:
• Connect the Keba power charging station to a switch or Ethernet router.
• Connect the Solar-Log™ to a switch or Ethernet router.
Assigning IP addresses
•
Configure the address according to the manufacturer‘s manual.
•
The DHCP range (IP address) for the Keba power charging station has to be in the same subnet as the So-
lar-Log™.
•
The charging station always obtains its IP address via DHCP. That is why the router for the charging station
must always assign the same IP address (static). (Refer to the router‘s manual).
Detection via the Solar-Log
™
WEB Interface
•
For detection on the Solar-Log
™
, select the device class under the menu Configuration | Device | Definition
| Interface
with the plus symbol and then select Keba as the manufacturer. Confirm your selection with OK.
•
Save your selections and then start the Device Detection under Configuration | Device | Detection.
Detection from the Solar-Log 1200
•
When using the Solar-Log 1200, the detection can also be started from the display. Select the settings ►Start
► Initial Configuration ► Page 2 „Device“ ► Add and select the manufacturer Keba from there. Save and start
the Device Detection.
