77.2 SchneiderElectricXantrexGT30E
Termination Addressing Interface
- No Sub D9 socket
Select “Schneider Electric: XantrexGT30E“ for the device detection.
Overview
•
Integrated interface
•
Where to connect: Sub D 9 socket X51 inside the inverter.
•
2-pin wiring
•
Communication address must be allocated to the inverter.
•
Installation steps
• Switch off the inverters and Solar-Log™
• Connect inverters to the Solar-Log™
• Connect the inverters to each other
Connect inverters to the Solar-Log™
The wiring is done using a
•
ready-made data cable (optional extra; not supplied)
•
self-made, shielded 2 wire data cable and terminal block connector
Procedure:
1. Open the inverter as shown in the inverter's instructions.
2. If you are making the cable yourself, connect the wires as shown in the following diagram
Solar-Log™ terminal strip connector Inverters
Terminal Sub D9 socket X51
► 1 ► 8
► 4 ► 6
3. Close the inverter if no other inverters are to be connected.
4. Insert the terminal block connector into the Solar-Log™ RS485 socket.
Connect the inverters to each other
•
Connect using a 2 wire, shielded data cable
•
Where to connect: Sub D 9 socket X51 inside the inverter.
Procedure
1. If you are making the cable yourself, connect the wires as shown in the following diagram
Solar-Log™ terminal strip connector Inverters
RS485/422 B Sub D9 socket X51
► 1 ► 8
► 4 ► 6
2. Connect the other inverters to each other in the same way (1:1).
3. Close the inverter if no other inverters are to be connected.
4. Insert the terminal block connector into the Solar-Log™ RS485 socket.
