Solare Datensysteme Solar-Log - 32.4 Fronius Symo; Fronius Symo Hybrid via Ethernet

130
Fronius
32.4 FroniusSymo/FroniusSymoHybridviaEthernet
Termination Addressing Interface
No Yes LAN
Select “Fronius: SunSpec Modbus/SolarAPI“ during the inverter detection.
Overview
•
Integrated interface.
•
The inverter‘s IP address has to be assigned.
•
Connect using network cable (patch cable) and Ethernet router or switch.
•
Installation steps:
• The inverter has to be assigned a static IP address.
• Switch off the inverters and the Solar-Log™.
• Connect inverters to the Solar-Log™ (RJ45).
• Connect the inverters to each other (RJ45).
Connect the inverters to the Solar-Log™.
The wiring is done using a
•
network cable (patch cable/crossover cable) and the
•
Ethernet router or switch.
Connect the inverters to each other.
The inverters are connected together using
the RJ45 interface and, if needed, a router or switch.
Follow the connection setup according to the inverter‘s instructions.
Assigning IP addresses
•
A static IP address has to be assigned to the inverter via the display.
•
Please select an IP address with the same class C subnet as the Solar-Log™.
For example: The Solar-Log™ has the IP address 192.168.178.49.
The inverter in this case has to have a free IP address in the same range (from 192.168.178.1 to
192.168.178.254).
•
Procedure: Start according to the inverter‘s instructions.
Note
The "Data export via Modbus" settings in the Fronius Symo inverter have to be changed to "TCP" in
order for the inverter detection to be successful.
► Follow the procedures according to the inverter manufacturer's manual.
Note
If the settings were switched to TCP, the automatically applied inverter settings should not be changes
because otherwise communication with the Solar-Log™ will not work.
