CanadianSolar
14 CanadianSolar
14.1 CanadianSolar-CSI-CTseries
Termination Addressing Interface
No Yes RS485
The following types are to be connected according to this diagram:
•
CSI-23KTL-CT
•
CSI-28KTL-CT
•
CSI-36KTL-CT
Select the inverter CanadianSolar for the inverter detection.
Overview
•
Integrated interface.
•
Where to connect: RJ45 socket on the outside of the inverter.
•
2-pin wiring.
•
The communication addresses (1-247) have to be assigned.
•
Installation steps:
• Switch off the inverters and Solar-Log™.
• Connect inverters to the Solar-Log™.
• Connect the inverters to each other.
• Allocate communication address.
Caution
Risk of damage to the unit!
The Solar-Log™ also has an RJ45 socket, which must never be connected to the RJ45 socket on the
inverter.
► Only connect inverters via the RS485/422 Solar-Log™ interface(s).
Connect inverters to the Solar-Log™
The wiring is done using a
•
self-made, shielded 2 wire data cable with a RJ45 socket and a terminal block connector.
