Solare Datensysteme Solar-Log - 80 SIEL; 80.1 SIEL (single phase)

280
SIEL
80 SIEL
80.1 SIEL(singlephase)
Termination Addressing Interface
Yes Yes RS485
Supported models:
•
Soleil 1F (1-phase) 1,5, 2, 3, 4, 5, 6
•
Soleil 10 TL
•
Soleil M 1.5, 2, 4, 4.6, 6
Overview
•
Interface not integrated; Retrofit RS485 interface card
•
2-pin wiring
•
The communication address has to be assigned
•
Installation steps
• Allocate communication address
• Switch off the inverters and Solar-Log™
• Install the RS485 interface in the inverter
• Connect inverters to the Solar-Log™
• Connect the inverters to each other
Allocate communication address
•
Recommendation: Continuous numbering starting with 1.
•
Setting: Using the DIP switch on the interface card.
Before installing the RS485 interface card:
► Allocate the communication address using the 8 interface card DIP switches:
Example - Communication address 1:
On
O
DIP switch
