Helios Systems
41.2 HeliosSystems-CentralInverters
Termination Addressing Interface
No Yes
LAN
Overview
•
Integrated interface
•
Connect using network cable (patch cable) and Ethernet router or switch.
•
Communication address must be allocated.
•
Installation steps
• Assign the communication address.
• Connect the inverters to the Solar-Log™.
• Connect the inverters to each other.
Caution
The IP addresses for the inverter has to be in the same Class C network as the Solar-Log™. Alternati-
vely, it is sufficient if the first three groups of digits in the IP addresses are the same.
Assign the communication address.
•
Setting: Using the inverter operating display.
Please follow the instructions in the manufacturer‘s manual.
Connect inverters and the Solar-Log™.
The wiring is done using a
•
network cable (patch cable) and the
•
Ethernet router or switch.
Procedure
1. Set different unit IPs on each inverter in accordance with the inverter‘s instructions.
2. Connect the Solar-Log™ and the inverter to the router or switch.
