Schneider Electric
10 SchneiderElectric
10.1 SchneiderEM6400S(3-phase)
Selections available under Schneider Electric
Supported by firmware 4.1.0 and higher
Overview
•
Communication address must be allocated.
•
2-pin wiring
•
Installation steps
• Switch off the meter and the Solar-Log™.
• Connect the meter to the Solar-Log™.
Connect the meter to the Solar-Log™.
The wiring is done using a
•
self-made cable connection with a terminal block connector.
Cable connection via RS485:
Solar-Log™ RS485 terminal block Solar-Log 50 Schneider EM4600S
Pin assignment Pin assignment
1 1 or 5 7 (D1)
4 4 or 6 14 (D0)
Termination: 120-ohm resistor at connection pin 7 and 14 on the meter
Note
The following parameters need to be checked before the device detection to ensure that the meter is
detected.
Baud rate: 9600 bps
Data bits: 8
Stop bits: 1
Parity: even
► The settings are adjusted via the device's display. (Please refer to the notes and instructions in the
meter's manual for instructions.)
