Heating rod MyPv AC ELWA-E
2 HeatingrodMyPvACELWA-E
2.1 HeatingrodMyPvACELWA-EviaEthernet
Termination Adressing Interface
No Yes LAN
Select „MyPv“ during the inverter detection.
Overview
•
Integrated interface.
•
Connect using network cable (patch cable) and Ethernet router or switch.
•
A static IP address must be assigned.
•
Installation steps:
• Switch off the heating rod and the Solar-Log™.
• Connect the heating rod to the Solar-Log™.
Connect the heating rod to the Solar-Log™
The wiring is done using a
•
Network cable (patch cable/crossover cable) and the
•
Ethernet router or switch.
Assign the IP address for detection and communication:
The MyPV heating rod is set to DHCP by default. A static IP address must be defined in its web menu. Both devices
need to be in the same subnet mask Detection via the Solar-Log™ WEB interface.
Detection via the Solar-Log™ WEB interface
•
For detection on the Solar-Log™, select the device class under the menu
•
Configuration | Device | Definition | Interface with the plus symbol and then select MyPv as the manufac-
turer. Confirm your selection with
OK
•
Save your selections and then start the Device Detection under Configuration | Device | Detection and start
the device detection
Detection from the Solar-Log 1200
•
When using the Solar-Log 1200, the detection can also be started from the display. Select the settings ► Start
► Initial Configuration ► Page 2 „Device“ ► Add and select the manufacturer „MyPv“ from there. Save and
start the Device Detection.
Note
For the communication with the Solar-Log™ to work,
the control type in the heating rod web menu has to be set to Modbus TCP and the power timeout to
60.
