Ingeteam
45 Ingeteam
45.1 INGECON®SUN1PlayTLM
Termination Addressing Interface
Jumper P3 Yes RS485
Supported models:
•
INGECON® SUN 1Play 2.5TL M
•
INGECON® SUN 1Play 3TL M
•
INGECON® SUN 1Play 3.3TL M
•
INGECON® SUN 1Play 3.68TL M
•
INGECON® SUN 1Play 4.6TL M
•
INGECON® SUN 1Play 5TL M
•
INGECON® SUN 1Play 6TL M
Note:
The SUN 1Play TL M models have 1 phase and 2 MPP tracker.
Overview:
•
Interface not integrated; Retrofit RS485 interface card.
•
3-pin wiring.
•
Communication address must be allocated.
•
Installation steps:
• Switch off the inverters and Solar-Log™.
• Install the RS485 interface in the inverter.
• Connect inverters to the Solar-Log™.
• Connect the inverters to each other.
• Allocate communication address.
Installing the RS485 interface
Procedure
► Install the RS485 interface in the inverter in accordance with the interface card installation instructions.
Connect inverters to the Solar-Log™
The wiring is done using a
•
self-made, shielded 3 wire data cable and terminal block connector.
