Solar-Log™ Meter Operating Modes
2 Solar-Log™MeterOperatingModes
2.1 ExplanationoftheSolar-Log™MeterOperatingModes
There are various setting options when configuring meters in Solar-Log™. These are in particular:
•
Battery meter (bi-directional meter):
• Records the battery charges and discharges.
•
Deactivated: The recording of consumption has been or is deactivated.
•
Meter for the entire plant: The entire production from all of the inverters.
•
Sub-consumer: Meter to record the individual consumption from appliances that was already recorded with a
consumption meter.
•
Utility Meter (U+I) (only Solar-Log 2000): Meter for control and reduction functions - including current measu-
rements if necessary with current transformers.
•
Utility Meter (U) (only Solar-Log 2000): Meter for control and reduction functions - only voltage measurements.
•
Utility Meter (U+I) + Consumption Meter (bi-directional) (only Solar-Log 2000):
Meters that are used as Utility Meters (U+I) can also be used as consumption meters
(bi-directional) in this mode.
•
Consumption meter: Meter that only records the consumption.
•
Consumption meter (Bi-directional meter): Meter that records consumption and production collectively - the
actual consumption is determined by monitoring the inverters.
•
Generator: The meter values are considered inverter values.
Note
Please make sure that the counter configuration under Configuration | Devices | Configuration |
Configuration
in the section „Module field, power & lable“, the value entered in the „Maximum AC
power“ field, the measuring range to be recorded and the scaling of the consumption graph, in the
Solar-Log ™, as well as in the WEB.
