45.5 INGECON®SUN3Play100k
Termination Addressing Interface
Jumper Yes RS485
Supported series (as of firmware 4.2.1):
•
INGECON® SUN 3Play 100k
Note:
The SUN 3Play 100k series have 3 phase and 1 MPP tracker.
Overview:
•
Integrated interface.
•
3-pin wiring.
•
Communication address must be allocated.
•
Installation steps:
• Switch off the inverters and Solar-Log™.
• Connect inverters to the Solar-Log™.
• Connect the inverters to each other.
• Allocate communication address.
Connect inverters to the Solar-Log™
The wiring is done using a
•
self-made, shielded 3 wire data cable and terminal block connector.
Procedure
1. Open the inverter as shown in the inverter‘s instructions.
2. Pull the free wires through the wire opening in the inverter.
3. If you are making the cable yourself, connect the wires as shown in the following diagram:
Solar-Log™ terminal strip connector Inverter terminal strip
Terminal Terminal
► 1 ► Pin 1 RS485 A (+)
► 3 ► Pin 6 GND
► 4 ► Pin 2 RS485 B (-)
4. If no further inverter connected, terminate the inverter:
Insert jumper into the RS485 card.
5. Close the inverter if no other inverters are to be connected.
6. Insert the terminal block connector into the Solar-Log™ RS485 socket.
Connect the inverters to each other
•
Connect using a 3 wire, shielded data cable.
•
Where to connect: Terminal strip inside the inverter.
