Voltwerk
106 Voltwerk
106.1 Voltwerk(onlySolar-Log1000,1900and2000)
Note
Voltwerk inverters can only be connected to the Solar-Log 1000, 1900 and 2000, as only this one has a
CAN interface.
The following description relates to inverters without transformers produced in or after 2007.
Termination Addressing Interface
Yes No CAN bus
Overview
•
CAN only to be used on Solar-Log 1000, 1900 and 2000 (CAN interface).
•
Integrated interface
•
Where to connect: CAN socket on the outside of the bottom of the inverter
•
Only use ready-made cable sets
Two different special cable sets must be ordered separately
- Prefabricated cable set between the Solar-Log 1000, 1900 and 2000 and the first inverter, including cable
termination
- Ready-made cable set with 5 pin Phoenix contact connection plug for connecting the inverters to each
other
The number of cables are required depends on the number of inverters
Maximum total cable length: 200 m
•
Communication address does not have to be assigned
•
Installation steps
• Switch off the inverters and Solar-Log™
• Connect inverters to the Solar-Log™
• Connect the inverters to each other
PIN assignment:
Solar-Log™ terminal strip connector Sensor / actuator connector 5-pin
Terminal Pin
4 not used 1 not used
5 not used 2 not used
► 1 ► 3
► 3 ► 4
► 2 ► 5
At Solarlog ™ set a 120 Ω resistor between PIN 2 and 3
