5.2 Inepro75D
Selections available under Inepro / DMM
Overview
•
The communication address cannot be freely assigned.
•
2-pin wiring.
•
Installation steps:
• Switch off the meter and the Solar-Log™.
• Connect the meter to the Solar-Log™.
Connect the meter to the Solar-Log™.
The wiring is done using a
•
self-made cable connection with a terminal block connector.
Cable connection via RS485:
Solar-Log™ RS485 terminal block Solar-Log 50 Inepro 75D
Pin assignment Pin assignment
1 1 or 5 8 - RS485A
4 4 or 6 7 - RS485B
Possible meter operating modes for the Inepro 75D meter via RS485:
•
Total plant metert
•
Sub-consumption meter
•
Consumption meter
•
Generator
Cable connection via S0:
Solar-Log™ S
0
terminal block Inepro 75D
Pin assignment Pin assignment
1 - S0+
6 - S0+
2 - S0- 5 - S0-
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.
Possible meter operating modes for the Inepro 75D meter via S0:
•
Total plant meter
•
Sub-consumption meter
•
Consumption meter
•
Generator
Impulse factor of the meter:
1600 p / kWh
