Solare Datensysteme Solar-Log - 45.2 INGECON SUN 3 Play TL

167
Ingeteam
45.2 INGECON®SUN3PlayTL
Termination Addressing Interface
Jumper Yes RS485
Supported models:
•
INGECON® SUN 3Play 10TL
•
INGECON® SUN 3Play 15TL
•
INGECON® SUN 3Play 20TL
•
INGECON® SUN 3Play 28TL
•
INGECON® SUN 3Play 33TL
Note:
The SUN 3Play TL models have 3 phase and 1 MPP tracker.
Overview:
•
Integrated interface.
•
3-pin wiring.
•
Communication address must be allocated.
•
Installation steps:
• Switch off the inverters and Solar-Log™.
• Install the RS485 interface in the inverter.
• Connect inverters to the Solar-Log™.
• Connect the inverters to each other.
• Allocate communication address.
Connect inverters to the Solar-Log™
The wiring is done using a
•
self-made, shielded 3 wire data cable and terminal block connector.
Procedure
1. Open the inverter as shown in the inverter‘s instructions.
2. Pull the free wires through the wire opening in the inverter.
3. If you are making the cable yourself, connect the wires as shown in the following diagram:
Solar-Log™ terminal strip connector Inverter terminal strip
Terminal Terminal
► 1 ► Pin 1 RS485 A (+)
► 3 ► Pin 6 GND
► 4 ► Pin 2 RS485 B (-)
4. If no further inverter connected, terminate the inverter:
Insert jumper into the RS485 card.
5. Close the inverter if no other inverters are to be connected.
6. Insert the terminal block connector into the Solar-Log™ RS485 socket.
