EGO Smart Heater
1.2 EGOSmartHeaterviaEthernet
Termination Addressing Interface
No -* LAN
Overview
•
Integrated interface.
•
Connected using network cable (patch cable) and Ethernet router or switch.
•
The communication address cannot be assigned (only via DHCP)*.
•
Installation steps:
• Switch off the heating rod and Solar-Log™.
• Connect the heating rod to the Solar-Log™.
Connect the EGO Smart Heater to the Solar-Log™
The wiring is done using a
•
network cable (patch cable) and the
•
Ethernet router or switch.
*Dynamic IP address (DHCP) for detection and communication:
Both the Solar-Log™ and the EGO Smart Heater devices have to be set to obtain their IP addresses automatically
(DHCP) and be in the same class C subnet.
Detection via the Solar-Log™ WEB Interface
•
For detection on the Solar-Log™ , select the device class under the menu Configuration | Device | Definition
| Interface
with the plus symbol and then select Benning as the manufacturer. Confirm your selection with
OK.
•
Save your selections and then start the Device Detection under Configuration | Device | Detection.
Detection from the Solar-Log 1200
•
When using the Solar-Log 1200, the detection can also be started from the display. Select the settings ►Start
► Initial Configuration ► Page 2 „Device“ ► Add and select the manufacturer EGO: Smart Heater from there.
Save and start the Device Detection.
Note
With the Ethernet version of EGO can be up to 6 EGO Smart Heater, controlled and prioritized via the
Smart Energy Function of the Solar-Log ™.
