Sungrow
93 Sungrow
93.1 Sungrow
Termination Addressing Interface
120 Ω resistor Yes RS485
Overview
•
Integrated interface.
•
Where to connect: RJ45 socket.
•
2-pin wiring.
•
Communication address must be allocated.
•
Installation steps:
• Switch off the inverters and Solar-Log™
• Connect inverters to the Solar-Log™
• Connect the inverters to each other
• Allocate communication address
Note
When a device has four MPP trackers, this will be recorded as a single MPP tracker.
► With firmware version 4.1.0 or higher, four MPP trackers are recorded.
Connect inverters to the Solar-Log™
The wiring is done using a
•
self-made shielded, 2-wire data cable with terminal block connector.
Procedure
1. If you are making the cable yourself, connect the wires as shown in the following diagram:
Solar-Log™ terminal strip connector RJ45 socket inverter
Terminal PIN
► 1 ► 6 (Data +A)
► 4 ► 3 (Data -B)
2. Insert the plug into the socket on the inverter
3. If no further inverter is connected, terminate the inverter according to the instructions for the inverter.
4. Insert the terminal block connector into the Solar-Log™ RS485 socket.
