SolaX Power
89 SolaXPower
89.1 SolaXPowerX1
Termination Addressing Interface
Yes Automatic RS422
The following types are to be connected according to this diagram:
•
SL-TL1500, SL-TL2200, SL-TL2500, SL-TL2800, SL-TL3000, SL-TL3300T, SL-TL3600T, SL-TL4400T, SL-TL5000T
Select SolaXPower X1 during the inverter detection.
Overview
•
Integrated interface
•
2 RJ45 sockets on the outside of the inverter
•
4-pin wiring - only on RS485/422 B or C connection of the Solar-Log™
•
Communication address does not have to be assigned
•
Installation steps
• Switch off the inverters and Solar-Log™
• Connect inverters to the Solar-Log™
• Connect the inverters to each other
Note
Only connect inverter using the RS485/422 B or C interface.
Connect inverters to the Solar-Log™.
The wiring is done using a
•
self-made, shielded 8 wire data cable and terminal block connector.
•
Where to connect: RJ45 socket on the inverter
Caution
Risk of damage to the unit!
The Solar-Log™ also has an RJ45 socket, which must never be connected to the RJ45 socket on the
inverter.
► Only connect inverters via the RS485/422 Solar-Log™ interface(s).
