Rainwise - PVMet™-200 (Weather station)
3 Rainwise-PVMet™-200(Weatherstation)
3.1 PVMet™-200(Weatherstation)
Termination Addressing Interface
-* No RS485
Selections available under Sensor/Rainwise/PVMet200.
Supported by firmware 4.1.0 and higher.
Overview
•
Integrated interface.
•
Where to connect: Terminal strip on circuit board under the cover.
•
Communication address does not have to be assigned.
•
4-pin wiring.
•
Installation steps:
• Switch of the PVMet™-200 and the Solar-Log™.
• Connect the PVMet™-200 to the Solar-Log™.
Connect the PVMet™-200 to the Solar-Log™.
The wiring is done using a
•
self-made, shielded 4-wire data cable with a terminal block connector.
Procedure
1. If you are making the cable yourself, connect the wires as shown in the following diagram:
Solar-Log™ terminal strip connector Terminal strip on circuit board
Terminal PIN
► 1 ► RS485 A-
► 3 ► Ground/GND
► 4 ► RS485 B+
*Termination:
Please contact Rainwise for information on termination.
Note
Only one PVMet™ -200 can be connected and visualized per Solar-Log™ device.
