Schneider Electric
10.2 SchneiderEM6400NG(3-phase)
Selections available under „Schneider Electric/EM6400NG“.
Overview
•
The communication address has to be assigned.
•
2-pin wiring.
•
Installation steps:
• Switch off the meter and the Solar-Log™.
• Connect the meter to the Solar-Log™.
Connect the meter to the Solar-Log™
The wiring is done using a
•
self-made cable connection with a terminal block connector.
Cable connection via RS485:
Solar-Log™ RS485 terminal block Solar-Log 50 Schneider EM4600NG
Pin assignment Pin assignment
► 1 1 or 5 ► 7 (D1 +)
► 4 4 or 6 ► 14 (D0 -)
Termination: 120-ohm resistor at connection pin 7 and 14 on the meter
Note
The following parameters need to be checked before the device detection to ensure that the meter is
detected.
Baud rate: 19200 bps
Data bits: 8
Stop bits: 1
Parity: even
► The settings are adjusted via the device‘s display. (Please refer to the notes and instructions in the
meter‘s manual for instructions.)
Possible meter operating modes for the Schneider EM6400S via RS485:
•
Battery meter (Bi-directional)
•
Total plant meter
•
Sub-consumer
•
Consumption meter
•
Consumption meter (bi-directional)
•
Generator
