SofarSolar
86 SofarSolar
86.1 SofarSolar
Termination Addressing Interface
Yes Yes RS485
Selection available under SofarSolar
Supported models (Wiring via RJ45) (as of firmware 4.1.0):
SOFAR 4.4KTL-X – 12KTL-X
SOFAR 10000TL – 20000TL
SOFAR 30000TL – 40000TL
SOFAR 50000TL – 70000TL
Supported models (Wiring via RS485 pin block) (as of firmware 4.1.0):
SOFAR 1100TL –3000TL
SOFAR 3000TLM – 6000TLM
SOFAR 3KTLM-G2 –SOFAR 6KTLM-G2
Overview
Integrated interface.
Where to connect: RS485 pin block, inside the inverter.
Where to connect: RJ45 socket inside the inverter.
2-pin wiring.
The communication address has to be assigned.
Installation steps:
Switch off the inverters and Solar-Log™
Connect inverters to the Solar-Log™.
Connect the inverters to each other according to the inverter instructions.
Connect inverters to the Solar-Log™ (via RJ45)
The wiring is done using a
self-made RS485 data cable with RJ45 plug and terminal block connector.
Procedure
1. Open the inverter as shown in the inverter‘s instructions.
2. If you are making the cable yourself, connect the wires as shown in the following diagram:
Solar-Log™ terminal strip connector RJ45 inverter
Terminal Pin
1 Data+ 2 RS485 A (+) (Orange)
4 Data- 1 RS485 B (-) (White and Orange)
