Janitza UMG 104 / UMG 604 / UMG 604-PRO (Utility Meter)
7.2 JanitzaUMG604/UMG604-PROviaEthernet
Termination Addressing Interface
No Yes LAN
Overview
•
Integrated interface.
•
Connect using network cable (patch cable) and Ethernet router or switch.
•
A static IP address must be assigned.
•
Installation steps:
• Switch off the Janitza device and the Solar-Log™.
• Connect the Janitza device to the Solar-Log™.
Connect Janitza to the Solar-Log™
The wiring is done using a
•
network cable (patch cable/crossover cable) and the
•
Ethernet router or switch.
Assign the IP address for detection and communication:
IP addresses assignment according to manufacturer’s instructions. Both devices need to be in the same subnet
mask.
Detection via the Solar-Log™ WEB Interface
•
For detection on the Solar-Log™ , select the device class under the menu Configuration | Device | Definition
| Interface
with the plus symbol and then select Janitza as the manufacturer. Confirm your selection with OK.
•
Save your selections and then start the Device Detection under Configuration | Device | Detection.
Detection from the Solar-Log 1200
•
When using the Solar-Log 1200, the detection can also be started from the display. Select the settings ►Start
► Initial Configuration ► Page 2 „Device“ ► Add and select the manufacturer Janitza from there. Save and
start the Device Detection.
Note
The meter operating modes via Ethernet are identical to those of the RS485 version.
