Ginlong
36 Ginlong
36.1 Ginlong
Termination Addressing Interface
Yes Yes RS485
Overview
•
Integrated interface.
•
Where to connect: Between the COM round sockets on the outside of the inverter.
•
2-pin wiring.
•
Communication address must be allocated.
•
Installation steps:
• Switch off the inverters and Solar-Log™.
• Connect inverters to the Solar-Log™.
• Connect the inverters to each other.
• Allocate communication address.
Note
When a device has four MPP trackers, this will be recorded as a single MPP tracker.
► With firmware version 4.1.0 or higher, four MPP trackers are recorded.
Information on the following models:
•
Solis-2.5K-4G
•
Solis-3K-4G
•
Solis-3.6K-4G
The models mentioned are available with one or two MPP trackers.
The models with a single MPP tracker have the ST (single tracker) at the end of the model name. Since the So-
lar-Log™ also detects models with two MPP trackers, the MPP not being used should be deactivated.
How to deactivate the MPP tracker:
Enter the value 0 for the module field and generator power in the Module field, Output & Label section under the
Configuration | Device | Configuration | Configuration menu. Then click „save.“
Note!
It is important to note that there are two different wiring types for the Ginlong model.
► Refer to the wiring table further below.
