Zucchetti Centro Sistemi S.p.a
112 ZucchettiCentroSistemiS.p.a
112.1 Azzuro
Termination Addressing Interface
Yes Yes RS485
Selection available under SofarSolar
Supported models (Wiring via RJ45) (as of firmware 4.1.1):
•
Azzuro 4.4KTL, 5.5KTL, 6.6KTL, 8.8KTL, 11KTL, 12KTL
•
Azzuro 10000TL, 15000TL, 17000TL, 20000TL
•
Azzuro 30000TL, 33000TL, 40000TL
•
Azzuro 50000TL, 60000TL, 70000TL
Supported models (Wiring via RS485 pin block) (as of firmware 4.1.1):
•
Azzuro 1100TL, 1600TL, 2200TL, 2700TL, 3000TL
•
Azzuro 3000TLM, 3680TLM, 4000TLM, 4600TLM, 5000TLM, 6000TLM
•
Azzuro 3KTLM, 3.6KTLM, 4KTLM, 4.6KTLM, 5KTLM, 6KTLM
Overview
•
Integrated interface.
•
Where to connect: RS485 pin block, inside the inverter.
•
Where to connect: RJ45 socket inside the inverter.
•
2-pin wiring.
•
The communication address has to be assigned.
•
Installation steps:
• Switch off the inverters and Solar-Log™
• Connect inverters to the Solar-Log™.
• Connect the inverters to each other according to the inverter instructions.
Connect inverters to the Solar-Log™ (via RJ45)
The wiring is done using a
•
self-made RS485 data cable with RJ45 plug and terminal block connector.
Procedure
1. Open the inverter as shown in the inverter‘s instructions.
2. If you are making the cable yourself, connect the wires as shown in the following diagram:
Solar-Log™ terminal strip connector RJ45 inverter
Terminal Pin
► 1 Data+ ► 2 RS485 A (+) (Orange)
► 4 Data- ► 1 RS485 B (-) (White and Orange)
