Zeversolar
Procedure
1. If you are making the cable yourself, connect the wires as shown in the following diagram:
Solar-Log™ terminal strip connector RJ45 inverter
Terminal PIN
► 1 ► Pin 3
► 4 ► Pin 6
► 5 ► Pin 1
► 6 ► Pin 2
2. Insert the RJ45 plug into any RJ45 socket on inverter 1.
3. If no further inverter is connected, terminate the inverter according to the instructions for the inverter.
4. Insert the terminal block connector into the Solar-Log™ RS485/422 B socket.
Connect the inverters to each other
•
Connect using a network cable (patch cable)
•
Where to connect: RJ45 socket on the outside of the inverter
Procedure
1. Insert the RJ45 plug into any RJ45 socket on inverter 1.
2. Insert the other end of the wire into any RJ45 socket on inverter 2.
3. Connect the other inverters to each other in the same way.
4. Terminate the last inverter according to the inverter instructions.
Note
All Zeverlution S, Zeverlution 3680/4000/5000 and Evershine TLC inverter models can be supplied as
an additional option with an already integrated monitoring solution (ComBox) from Zeversolar. If one
of these models is purchased with an integrated solution, it is not possible to connect a third-party
monitoring system. Therefore there is no compatibility to Solar-Log™.
