Secure Meters
11 SecureMeters
11.1 SecureMeters(3-phase)
Selections available under „Secure“.
Supported Series/Models (as of firmware version 4.2.0):
•
Series Elite 440:
•
Models:
• 445, 446, 447
Overview
•
The communication address has to be assigned.
•
2-pin wiring.
•
Installation steps:
• Switch off the meter and the Solar-Log™.
• Connect the meter to the Solar-Log™.
Connect the meter to the Solar-Log™
The wiring is done using a
•
self-made cable connection with a terminal block connector.
Cable connection via RS485:
Solar-Log™ RS485 terminal block Solar-Log 50 Secure Meter (RS485)
Pin assignment Pin assignment
► 1 + 1 or 5 ► +
► 4 - 4 or 6 ► -
Note
The following parameters need to be checked before the device detection to ensure that the meter is
detected:
Baud rate: 9600 bps
Data bits: 8
Stop bits: 1
Parity: Non
► The settings are adjusted via the device‘s display. (Please refer to the notes and instructions in the
meter‘s manual for instructions.)
