AROS Solar Technology
9 AROSSolarTechnology
9.1 AROSSolarTechnology(RS422)
Termination Addressing Interface
Yes No RS422
Select "AROS: SIRIO RS422" during the inverter detection.
Overview
•
Integrated interface.
•
Where to connect: Terminal strip inside the inverter.
•
4-pin cable only on RS485/422 B or C connection of the Solar-Log™.
•
Communication address does not have to be assigned.
Note
The order in which the inverters are displayed in the Solar-Log™ after detection is random. We strongly
recommend that you change the order of the inverters immediately after detection at startup in the
Configuration | Device | Configuration | Order menu box.
► The inverters can be identified using the displayed serial number.
•
Installation steps:
• Switch off the inverters and Solar-Log™.
• Connect inverters to the Solar-Log™.
• Connect the inverters to each other.
Connect inverters to the Solar-Log™
The wiring is done using a
•
self-made cable connection with terminal block connector.
