Chint Power
16 Chint Power
16.1 ChintPower(CPSSCandCPSSCEto20k)
Termination Addressing Interface
Yes Yes RS422
Overview
•
Interface not integrated; Retrofit RS485 interface card.
•
Where to connect: RJ45 socket on the outside of the inverter.
•
4-pin cable – only on RS485/422 B or C connection of the Solar-Log™.
•
Communication address does not have to be assigned.
Note:
The order in which the inverters are displayed in the Solar-Log™ after detection is random. We strongly
recommend that you change the order of the inverters immediately after detection at startup, in the
Configuration | Devices | Configuration | Order dialog box.
► The inverters can be identified using the displayed serial number.
•
Installation steps:
• Switch off the inverters and Solar-Log™.
• Install the RS485 interface in the inverter.
• Connect inverters to the Solar-Log™.
• Connect the inverters to each other.
Select the Chint CPS<20k inverter during the initial configuration.
Installing the RS485 interface
Procedure
► Insert the RS485 interface in the bottom of the inverter in accordance with the interface card installation inst-
ructions and screw in.
Connect inverters to the Solar-Log™
The wiring is done using a
•
ready-made BRJ1 data cable (optional extra; not supplied)
or
•
self-made cable connection with RS485 data cable and terminal block connector.
