371
Trannergy
101 Trannergy
101.1 Trannergy
Termination Addressing Interface
Yes No RS422
Overview
Interface not integrated; Retrofit RS485 interface card
4-pin cable – only on RS422 B or C connection of the Solar-Log™
Communication address does not have to be assigned
Multi-string technology
The Trannergy inverters are fitted with 1 or 3 MPP trackers depending on the model. Each string input is monito-
red separately and ideally adjusted to the connected modules.
The Solar-Log™ automatically detects how many inverters and strings are active during inverter detection.
Note:
The order in which the inverters are displayed in the Solar-Log™ after detection is random. We strongly
recommend that you change the order of the inverters immediately after detection at startup, in the
Configuration | Devices | Configuration | Order dialog box.
The inverters can be identified using the displayed serial number.
Installation steps
Switch off the inverters and Solar-Log™
Install the RS485 interface in the inverter
Connect inverters to the Solar-Log™
Connect the inverters to each other
Installing the RS485 interface
Procedure
Insert the RS485 interface in the bottom of the inverter in accordance with the interface card installation inst-
ructions and screw in.
Connect inverters to the Solar-Log™
The wiring is done using a
ready-made data cable (optional extra; not supplied)
or
self-made, shielded 4 wire data cable and terminal block connector
