Solare Datensysteme Solar-Log - 50.3 Kostal Ethernet Version

193
Kostal and Solar-Fabrik
50.3 KostalEthernetVersion
Termination Addressing Interface
No Yes LAN
Overview
•
Integrated interface
•
Connected using network cable (patch cable) and Ethernet router or switch
•
Communication address must be allocated
•
Installation steps
• Assign a static IP address
• Switch off the inverters and Solar-Log™
• Connect inverters to the Solar-Log™ (RJ45)
• Connect the inverters to each other (RJ45)
Note:
The RS485 bus address of every inverter has to be configured to 255 so that the Solar-Log can commu-
nicate with the inverter.
► Starting with firmware version 3.2.1, inverters set up with bus address 1 are supported.
► The bus address is determined once during the inverter detection process. For this reason, it
is not possible to change it while in operation (the Solar-Log™ would then no longer be able to
access the inverters). If this has accidentally happened, perform the inverter detection again to be
able to access the inverter from the Solar-Log™.
Connect inverters to the Solar-Log™
The wiring is done using a
•
network cable (patch cable/crossover cable) and the
•
Ethernet router or switch.
Connect the inverters to each other
The inverters are connected together using
the RJ45 interface and, if needed, a router or switch.
Connection setup according to the inverter's instructions.
Assigning IP addresses
•
A static IP address has to be assigned to the inverter via the display.
•
Please select an IP address with the same class C subnet as the Solar-Log™.
For example: The Solar-Log™ has the IP address 192.168.178.49.
The inverter in this case has to have a free IP address in the same range (from 192.168.178.1 to
192.168.178.254).
•
Procedure: Start according to the inverter's instructions
