6.2 IskraWS0031
Overview
•
2-pin wiring.
•
Installation steps:
• Switch off the meter and the Solar-Log™.
• Connect the meter to the Solar-Log™.
Connect the meter to the Solar-Log™.
The wiring is done using a
•
self-made cable connection with a terminal block connector.
Cable connection via S0:
Solar-Log™ S
0
terminal block Iskra WS0031
Pin assignment Pin assignment
1 - S0+ S0+
2 - S0- S0-
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.
Possible meter operating modes for the Iskra WS0031 meter via S0:
•
Total plant meter
•
Sub-consumption meter
•
Consumption meter
•
Generator
Impulse factor of the meter:
500 p / kWh
