Mikro PowerMeter
9 MikroPowerMeter
9.1 MikroPowerMeterDPM680
Auswählbar unter „Mikro:DPM680“
Overview
•
The communication address has to be assigned.
•
3-pin wiring.
•
Installation steps:
• Switch off the meter and the Solar-Log™.
• Connect the meter to the Solar-Log™.
Connect the meter to the Solar-Log™.
The wiring is done using a
•
self-made cable connection with a terminal block connector.
Cable connection via RS485:
Solar-Log™ RS485 terminal block Solar-Log 50 Mikro PowerMeter DPM680
Pin assignment Pin assignment
► 1 1 or 5 ► +
► 3 4 or 6 ► GND
► 4 ► -
Note
The default RS485 communication parameters for the meter are:
Baud: 38400
Data bits: 8
Parity: None
Stop bits: 1
The Solar-Log™ can only communicate with the meter when it has these settings. It is important to
check the settings before performing the device detection.
► Assign the communication address (according to the manufacturer‘s manual).
► The settings are adjusted via the device‘s display. (Please refer to the notes and instructions in the
manufacture‘s manual for instructions.)
