Phonosolar
2 Phonosolar
2.1 PhonoCube7.2(BatteryHybridSystem)
Termination Addressing Interface
No Yes RS485
Selections available under Phonosolar
Note on Solar Log
200
When detecting a PhonoCubes, two devices are always detected. The first device consists of the inver-
ter and the battery value. The second device consists of the consumption meter that is integrated into
the PhonoCube.
Note on Solar Log
200
The Solar Log
200
is designed for an inverter. Since two devices are always detected with a
PhonoCube, it cannot be connected to a Solar-Log
200
.
Overview
•
Integrated interface.
•
Where to connect: Terminal strip under the cover on the backside.
•
The communication address has to be assigned.
•
2-pin wiring.
•
Installation steps:
• Switch off the PhonoCube and Solar-Log™.
• Connect the PhonoCube to the Solar-Log™.
• Connect the PhonoCubes to each other.
• Allocate communication address.
Address range 1 - 247.
Settings according to the manual.
Connect the PhonoCube to the Solar-Log™
The wiring is done using a
•
self-made, shielded 4-wire data cable with a terminal block connector.
