Solare Datensysteme Solar-Log - 100 TBEA; 100.1 TBEA

369
TBEA
100 TBEA
100.1 TBEA
Termination Addressing Interface
120 Ω resistor Yes RS485
Supported models (as of firmware 4.2.0):
•
TS50KTL-S
Overview
•
Integrated interface
•
Where to connect: Round sockets on the outside of the inverter.
•
2-pin wiring
•
The communication address has to be assigned.
•
Installation steps
• Switch off the inverters and Solar-Log™
• Connect inverters to the Solar-Log™
• Connect the inverters to each other
• Assign the communication address; address range 1 to 247
Connect inverters to the Solar-Log™
•
self-made, shielded 2 wire data cable with round plug and terminal block connector.
Procedure
1. If you are fabricating the cable yourself, connect the wires as shown in the following diagram.
Solar-Log™ terminal strip connector Inverter
Terminal PIN
► 1 ► A1 or A2
► 4 ► B1 or B2
2. Insert the round plug into the COM round socket 1 on the inverter.
3. If no further inverter is connected, terminate the inverter according to the instructions for the inverter.
4. Insert the terminal block connector into the Solar-Log™ RS485 socket.
Connect the inverters to each other
•
Connect using a data cable with a round plug
•
Where to connect: Round sockets on the outside of the inverter.
