Solare Datensysteme Solar-Log - 5 sonnen; 5.1 sonnen Eco 6.0; 7.0

453
sonnen
5 sonnen
5.1 sonnenEco6.0/7.0
Termination Addressing Interface
No -* LAN
Select „sonnen“ during the inverter detection
Overview
•
Integrated interface
•
Connect using network cable (patch cable) and Ethernet router or switch.
•
The communication address cannot be assigned (only via DHCP).*
•
Installation steps
• Switch off the battery system and Solar-Log™.
• Connect the battery system to the Solar-Log™.
• Connect the inverters to the Solar-Log™ according to the inverter instructions.
• Assign the inverter‘s communication address according to the inverter instructions (if required).
Connect the battery system to the Solar-Log™.
The wiring is done using a
•
network cable (patch cable/crossover cable) and the
•
Ethernet router or switch.
Connect the inverters to each other.
The inverters are connected together according to the inverter instructions.
*Dynamic IP address (DHCP) for detection and communication:
Both the Solar-Log™ and sonnen Eco 6.0 / 7.0 devices have to be set to obtain their IP addresses automatically
(DHCP) and be in the same class C subnet. (The settings for DHCP according the sonnen Eco 6.0 / 7.0 manufactu-
rer‘s instructions.)
Detection via the Solar-Log™ WEB interface
•
For the device detection on the Solar-Log
™
select „Sonnenbatterie“ in the Network section from the Configu-
ration | Devices | Definition
menu and then click on Save..
Detection from the Solar-Log 1200
When using the Solar-Log 1200, the detection can also be started from the display.
•
Select „Sonnenbatterie“ from the „Network“ interface for the detection and then start the detection.
