SMA
84.10 SMA-SunspecModbus
Termination Addressing Interface
No Yes LAN
Select “SMA: Sunspec Modbus“ for the device detection.
Supported models:
•
Sunny Tripower 60
•
Sunny Highpower 75-10 (Peak1/SHP75)
Overview
•
Integrated interface
•
The inverter‘s IP address has to be assigned per DHCP.
•
Connect using network cable (patch cable) and Ethernet router or switch.
•
Connecting the SMA Inverter Manager
•
Installation steps
• Turn the Solar-Log™ off.
• Connect the inverters to each other.
• Connect the inverters to the SMA Inverter Manager.
• Connect the SMA Inverter Manager to the router/switch.
• The inverters are assigned IP addresses via the SMA Inverter Manager per DHCP (default setting).
• Connect the Solar-Log™ to the router/switch.
Connect the inverters to each other.
The inverters are connected together according to the inverter instructions.
Connect the inverters to the SMA Inverter Manager.
•
Wire connections according to the inverter instructions.
Connecting the Solar-Log™/SMA Inverter Manager
•
Connect the Solar-Log™ to the router/switch.
•
Connect the SMA Inverter Manager to the router/switch.
Assigning IP addresses
•
The inverters are assigned IP addresses via the SMA Inverter Manager.
Note
In order to perform the device detection for the inverters, the inverters first have to be set up accor-
ding to the SMA instructions.
