Procedure
1. If you make the cable yourself, connect the wires as shown in the diagram:
Terminal strip inside the rst inverter Terminal strip inside the second inverter
Terminal Terminal
► JX2 - A ► JX2 - A
► JX2 - B ► JX2 - B
2. Wiring the remaining inverters in the same way.
3. Terminate the last inverter according to the inverter instructions.
4. Insert the terminal block connector into the Solar-Log™ RS485 socket.
Procedure
1. Connect the data cable to the blocks JX2 A and B on inverter 1.
2. Connect the data cable to the blocks JX2 A and B on inverter 2.
3. Connect the remaining inverters in the same way.
4. Terminate the last inverter according to the manufacturer's instructions.
5. Close the inverter if no other inverters are to be connected.
6. Insert the terminal block connector into the Solar-Log™ RS485 socket.
Notes on inverter addresses
•
Recommendation: Continuous numbering starting with 1.
•
Settings: On the inverter operating display.
•
Procedure: Follow the manufacturer's documentation for the inverter.
Note
A maximum of 16 inverters can be connected per RS485 bus.
