Solar-Log™ terminal strip connector RJ45 inverter
Terminal PIN
► 1 ► Pin 3
► 4 ► Pin 6
► 5 ► Pin 1
► 6 ► Pin 2
1. Insert the RJ45 plug into any RJ45 socket on inverter 1.
2. If no further inverter is connected, terminate the inverter according to the instructions for the inverter.
3. Close the inverter if no other inverters are to be connected.
4. Insert the terminal block connector into the Solar-Log™ RS485/422 B or C socket.
Connect the inverters to each other
•
Connect using a network cable (patch cable).
•
Where to connect: RJ45 socket inside the inverter.
Procedure
1. Open the inverter as shown in the inverter's instructions.
2. Insert the RJ45 plug into any RJ45 socket on inverter 1.
3. Insert the other end of the wire into any RJ45 socket on inverter 2.
4. Connect the other inverters to each other in the same way.
5. Terminate the last inverter according to the inverter instructions.
6. Close inverters.
