GoodWe
Procedure (DT serie / SDT 10KL&15KW)
1. Connect wires as shown in the diagram:
Solar-Log™ terminal strip connector Terminal strip in the inverter
Terminal Terminal
► 1 + ► 1 RS485 +
► 4 - ► 2 RS485 -
2. Pass the cable from Solar-Log™ to inverter 1 through the cable gland on the underside of the device and
connect it to the RS485-Out terminal strip.
3. Plug the terminal strip plug into the RS485 socket of the Solar-Log™.
Wechselrichter untereinander verkabeln
•
Wiring via 2-pin cable with terminal strip plug.
•
Where to connect:: RS485 in the inverter.
Procedure:
1. Connect inverter 1 via RS485 terminal strip according to manufacturer‘s instructions.
2. Connect inverter 2 via RS485 terminal strip from inverter 1 according to manufacturer‘s instructions.
3. Connect the other inverters to each other in the same way.
4. Insert the terminal block connector into the Solar-Log™ RS485 socket.
5. Terminate the last inverter according to the inverter instructions.
Procedure (MT serie)
1. Connect wires as shown in the diagram:
Solar-Log™ terminal strip connector Terminal strip in the inverter
Terminal Terminal
► 1 + ► 1 485_TX+
► 3 GND ► 3 PE (Earth)
► 4 - ► 2 485_TX-
► or
► 1 + ► 5 485_TX+
► 3 GND ► 4 PE (Earth)
► 4 - ► 6 485_TX-
2. Pass the cable from Solar-Log™ to inverter 1 through the cable gland on the underside of the device and
connect it with terminal strip plug.
3. Plug the terminal strip plug into the RS485 terminal strip of the inverter.
4. Plug the terminal strip plug into the RS485 socket of the Solar-Log™.
