Huawei
Procedure (Version RS485 terminal block):
1. Open the inverter as shown in the inverter‘s instructions.
2. For self-assembly of the cable connection, connect the cables to the RS485 terminal block using the diagram
above.
3. Connect the remaining inverters with the network cable.
4. Terminate the last inverter in accordance with the manufacturer‘s specifications.
5. Close the inverter if no other inverters are to be connected.
6. Insert the terminal block connector into the Solar-Log™ RS485 socket.
Connect the inverters to each other
•
Connect using a network cable (patch cable).
•
Where to connect: 2 RJ45 sockets.
•
Wiring of the inverters according to the instructions for the inverter.
Wiring tables:
The following table is for the following models:
SUN2000-8KTL, 10KTL, 12KTL, 15KTL, 17KTL ,20KTL, 23KTL, 28KTL, 33KTL, 33KTL-A, 33KTL-US, 36KTL, 36KTL-US,
40KTL, 40KTL-US, 42KTL, 45KTL-US-HV-D0, 55KTL-HV-D1/D1-001, 55KTL-IN-HV-D1 and 60KTL-HV-D1/D1-001
Solar-Log™ terminal strip connector RJ45 inverter (RS485-Out)
Terminal PIN
► 1 ► 1 or 4
► 4 ► 2 or 5
The following table is for the following models:
SUN2000-33KTL and 40KTL
Solar-Log™ terminal strip connector RS485 terminal block
Klemme Pin
► 1 6 RS485 A (Out)
► 4 8 RS485 B (Out)
The following table is for the following models:
SUN2000-33KTL-A, 33KTL-US, SUN2000-36KTL, 36KTL-US, 40KTL-US, 42KTL, 45KTL-US-HV-D0, 55KTL-HV-D1/D1-001,
55KTL-IN-HV-D1 and 60KTL-HV-D1/D1-001
Solar-Log™ terminal strip connector RS485 terminal block
Klemme Pin
► 1 A (Out)
► 4 B (Out)
