Solar-Log™ terminal strip connector X4 socket inverter
Terminal PIN
► 1 4 - Data+
► 4 2 - Data-
3. Connect the Solar-Log™ cable to socket A on the first inverter.
4. According to the same wiring diagram, connect socket B on the first inverter to socket A on the second inver-
ter using the following diagram.
X4 socket inverter 1 X4 socket inverter 2
Terminal PIN
► 2 2 - Data+
► 4 4 - Data-
5. Connect the other inverters to each other in the same way.
6. Terminate the last inverter in accordance with the inverter instructions.
7. Insert the terminal block connector into the Solar-Log™ RS485 socket.
Note:
According to the manufacturer's specifications, a maximum of 31 devices can be connected per RS485
bus.
